Pulsar Axion 2 LRF XQ35 Pro Thermal Spotter
*UK Users Only*
Finance options available
Learn moreCompact thermal imager with enhanced, long range image quality
The Pulsar XQ series is expanding! Welcome to the Pulsar Axion 2 LRF PRO thermal spotter! Offering an even greater thermal imaging experience than its predecessor, this device features an extremely sensitive 384×288, 17µm sensor with an outstanding <25mK NETD rating for unparalleled levels of thermal sensitivity. Combining this with a powerful 35mm f1.0 fast aperture germanium objective lens provides users with an outstanding 1300m detection range.
It is also compatible with Pulsar's NEW Stream Vision 2 software.
Find our Pulsar Comparison Tool here
Product details
Key Features
- Lynred 384x288, 17µm, <25 mK NETD sensor
- Long detection range of 1.8m tall object up to 1300m
- Built-in precision laser rangefinder
- Fast start up within 5 seconds
- Up to 11 hours battery life on a single charge
- Built in video and still image recorder
- Variable magnification from 2x - 8x (x4 digital zoom)
- High contrast 640x400 AMOLED display
- Picture in Picture (PiP) mode
- Stream Vision 2 compatible
- Fast aperture 35mm f1.0 germanium objective lens
- Wide angle eyepiece
- Built-in Wi-Fi module
- 8 colour palettes
- IPX7 waterproof
Product Technology
Axion 2 Pro is designed for constant, often hard use. A magnesium alloy housing is light and strong at the same time. The housing reliably protects the internal components of a thermal imaging device from shocks, drops, moisture, heat or cold.
Specifications
| Microbolometer | |
| Type | uncooled |
| Resolution, Pixels | 384x288 |
| Pixel Pitch, µm | 17 |
| NETD, mK | < 25 |
| Frame Rate, Hz | 50 |
| Optical Characteristics | |
| Optical Magnification, x | 2 |
| Smooth Digital Zoom | 2-8 |
| Digital Zoom, x | x1, x2, x4 |
| Lens Focus, mm | 35 |
| Relative Aperture, D/f' | 1.0 |
| Minimum Focus Distance, m/y | 5 / 5.47 |
| Eye Relief Diameter, mm/inch | 4 / 0.16 |
| Angular Field of View (Horizontal x Vertical), degree | 10.7х8 |
| Linear Field of View, m at 100 m | 18.2 |
| Eyepiece Focus Range, Dioptre | +4 / -5 |
| Detection Distance for Deer-Sized Objects, m/y | 1300 / 1422 |
| Display | |
| Type | AMOLED |
| Resolution, Pixels | 640x400 |
| Operational Characteristics | |
| Power Supply, V | 3 - 4.2 |
| Battery Type/Capacity/Nominal Output Voltage | APS 5 Li-ion Battery Pack / 4900 mAh / DC 3.7 V |
| External Power Supply | 5 V, 9 V (USB Type-C) |
| Battery Run Time at t=22°C, hours* | 11 |
| Degree of Protection, IP Code (IEC60529) | IPX7 |
| Operating Temperature Range, °C / °F | -25 … +40 / -13 – +104 |
| Dimensions, mm/inch | 152x74x75 / 5.98x2.91x2.95 |
| Weight (with battery), kg/oz | 0.47 / 16.58 |
| Video Recorder | |
| Photo/Video Resolution, Pixels | 528x400 |
| Video/Photo Format | .mp4 / .jpg |
| Built-in Memory | 16 GB |
| Wi-Fi Channel | |
| Frequency | 2.4/5 GHz |
| Standard | IEEE 802.11 b/g/n/ac |
| Characteristics of the Rangefinder | |
| Wavelength, nm | 905 |
| Measurement Range, m/y*** | 1000/1094 |
| Measurement Accuracy, m | 1 |
